型号Model
XD8038AC |
频率Freq
Hz |
电压Voltage
VAC |
轴承Bearing Style |
电流Current
AMP |
功率 Power Watts |
速度
Speed
RPM |
风量Airflow
CFM |
风压Pressure
mmH2O |
噪音Noise dBA |
重量
Weight |
|
编号 P/N |
|
XD8038A1HSL |
50/60 |
110 |
S |
0.15/0.13 |
16.5/14.3 |
2300/2700 |
32/35 |
3.2/4.5 |
31/35 |
340g |
|
XD8038A1HBL |
50/60 |
110 |
B |
0.15/0.13 |
16.5/14.3 |
2400/2800 |
33/36 |
3.4/4.9 |
32/36 |
|
XD8038A2HSL |
50/60 |
220 |
S |
0.07/0.06 |
15.4/13.2 |
2300/2700 |
32/35 |
3.2/4.5 |
31/35 |
|
XD8038A2HBL |
50/60 |
220 |
B |
0.07/0.06 |
15.4/13.2 |
2400/2800 |
33/36 |
3.4/4.9 |
32/36 |
|
XD8038A3HSL |
50/60 |
380 |
S |
0.04/0.03 |
15.2/11.4 |
2300/2700 |
32/35 |
3.2/4.5 |
31/35 |
|
XD8038A3HBL |
50/60 |
380 |
B |
0.04/0.03 |
15.2/11.4 |
2400/2800 |
33/36 |
3.4/4.9 |
32/36 |
|
S 表示含油轴承, B 表示滚珠轴承. |
插片式风扇,把型号中的 L 改成 T . |
|
绝缘度：10MΩ at 500VDC between lead and frame |
内压：1 min at 1500VAC/50-60HZ ,current〈5mA |
|
工作温度：-20ºC～80ºC |
工作湿度：20%～85% |
|
工作电压：85V～125V for 110V and 190V～250V for 220V |
常温工作时间：滚珠轴承5万小时，含油轴承2万小时 |
|
|
|
Conversion Table of Airflow |
|
CFM |
m3/sec |
m3/min |
ft3/sec |
|
2118 |
1 |
60 |
35.31 |
|
35.31 |
0.01666 |
1 |
0.5885 |
|
60 |
0.02832 |
1.69833 |
1 |
|
1 |
0.00047 |
0.02832 |
0.01666 |
|
Conversion Table of Air Pressure |
|
mmH2O |
inH2O |
Pa=N/m |
afm <, /TD> |
|
1 |
0.03939 |
9.80665 |
0.00009 |
|
25.4 |
1 |
249 |
0.00246 |
|
0.10197 |
0.0040 |
1 |
0.00001 |
|
10332 |
407.1 |
101325 |
1 |
|
|
|
|
